Overview
Essential details
Design:
Two Post
Type:
Double Cylinder Hydraulic Lift
Lifting Capacity:
4000kg
Place of Origin:
China
Brand Name:
SATA
Model Number:
AE5102-3
Warranty:
1 Years
Rated load:
4 Ton
Voltage:
220v
Motor power:
2 .2kw
Electric control mode:
24VSecurity control box
Unlock method:
Manual unilateral
Overall Height:
3900mm
Inside column width:
3000mm
Min#Height:
95mm
Maximum lift height:
1990mm
Supply Ability
Supply Ability
5000 Set/Sets per Month
Packaging & delivery
Packaging Details
As international packing.
Port
shanghai
Lead time:
Quantity(units) 1 - 5 >5 Lead time (days) 10 To be negotiated
Wholesale SATA AE5102-3 4T manual 2 post car lift workshop repair hydraulic lift.
Specification
Product No.AE5102-3
Trat and high bush length70mm
Maximum lift height1990mm
Loaded rising time60s
Load falling time50s
Motor power2.2KW
Motor shellaluminum alloy
Unlock methodManual unilateral
Overall Height3900mm
Inside column width3000mm
External width of plate3580mm
Tray thread3knots 70mm adjustable
Arm type2+3straight arm
Electric control mode24VSecurity control box
base plate fixed hole positionunilateral 8pcs
MADE INChina
Voltage380V
Rated load4ton
Min#Height95mm
Introduction
| 24V safe voltage control | |||||
| With an safety mechanism on one side for manual unlocking; the safety mechanism automatically locks itself when a hand is away from the mechanism | |||||
| Motor with aluminum alloy housing, featuring fast heat dissipation | |||||
| Directly-driven oil cylinder, avoiding chain fracture risks | |||||
| 2 sections of straight bracket arms + 3 sections of straight bracket arms, suitable for more models | |||||
| With 16 pieces of M18x160 expansion bolts | |||||
| Tray with high bush as standard, for SUV models | |||||
| Sliding table lengthened to 1950MM with strength improved | |||||
| Sliding blocks increased from 2 sets to 3 sets, increasing the area under load and improving stability | |||||
| Sliding table welded by 16mm steel sheets, with strength improved | |||||
| Bracket arm safety mechanism with helical teeth design, ensuring perfect gear mesh |
