new type single phase din rail analog active energy meter with step motor type impulse register

Product Description

Model YEM011AG-A single phase electronic DIN rail active energy meter is a kind of new style single

phase two wire active energy meter, it adopts micro-electronics technique, and imported large scale

integrate circuit, uses advanced technique of digital and SMT techniques, etc. The meter completely

accords with relevant technical requirements of class 1 single phase active energy meter stipulated in

international standard IEC 62053-21. It can accurately and directly measure 50Hz or 60Hz active energy

consumption from single phase AC electricity net, it can display total energy consumption by step

motor type impulse register. It has following features: good reliability, small volume, light weight,

specious nice appearance, convenient installation, etc.

Functions

1. 35mm standard DIN rail installation, complying with standard DIN EN50022. Or front board setting

(mounting holes center distance 63 mm), users can choose any one by themselves.



2. Six pole width (Modulus 12.5mm), complying with standard JB/T7121-1993.



3. Standard configuration 5+1 digits display (99999.1kWh) by step motor type impulse register. May

select 6+1 digits display (Product Configuration code is AK).



4. Standard configuration one port of pulse output passive(polarity),May select increase a distant

port of pulse output passive (nonpolarity), (Product Configuration code is AI). And contact with all

kind of AMR system conveniently,complying with standard IEC 62053-31 and DIN 43864.



5. Two LED instructions power supply state (green) and signal of energy impulse (red).



6. Standard configuration don’t detection direction of the flow of load current. May select automatic

detection the direction of the flow of load current. And instructions (only red energy impulse signal

when working, that is meaning the direction of the flow of load current reverse).



7. Single direction measure single phase two wire active energy consumption. It is nothing with

direction of the flow of load current. Complying with standard IEC 62053-21.



8. Directly connect operationthere is two types wiring you may select. Standard configuration typeS

wiring, may select type T wiring (Product Configuration code is TG).



9. Standard configuration short terminals cover, may select extension terminals cover, in order to

protect to use safety. (Product Configuration code is AH).
