Overview

Essential details

• Place of Origin:

• Zhejiang, China

• Brand Name:

• Yomin Energy meter

• Model Number:

• YEM073UK Energy meter

• Display Type:

• Analog Only

• Phase:

• Single Phase

• Measuring Energy Range:

• 5(20)A,10(40)A,20(80)A,30(100)A

• Accuracy Class:

• 1.0

• Output Voltage:

• 127V,230V

• Operating Temperature:

• -20°C~+60°C

• Dimensions:

• 211x124x115mm

Supply Ability

• Supply Ability

• 20000 Piece/Pieces per Month

Packaging & delivery

• Packaging Details

Export Carton

• Port

Ningbo or Shanghai

• Lead time:

• Shipped in 5 days after payment

ISO 9001 Factory YEM073UK Single phase electromechanical front board installed active counter energy meter   Model:YEM073UK

Product Description

Model YEM073UK single phase electromechanical front board installed active

energy meter is a kind of new style single phase two wire active energy meter, it

is designed on the basis of original DD862 single phase electromechanical meter,

and fully absorbs new technologies about electromechanical meter from

domestic and abroad. The meter completely accords with relevant technical

requirements of class 2 single phase active energy meter stipulated in

international standard IEC 62053-11. It can accurately and directly measure 50Hz

or 60Hz active energy consumption from single phase AC electricity net, it is

used for setting indoor or out door meter box. The meter has novel design,

rational structure, and it can display total energy consumption by drum wheel

mechanical register. It has following features: high overload, power loss, long-

life, specious appearance, etc.

Features

1. Front board three fixed installation, the cover is made ABS engineering plastics molded overall, has a transparent glass window, the bottom of the meter is made of quality steel which is after double-through antirust processing, and the terminal is made of quality bakelite material which is moisture-resistant, fire-retardant, high temperature molded overall. It has following features: economy benefits, specious appearance, etc.

2. The meter frame adopt aluminum molding with excellent mechanical strength, stable structure and anti-impact.

3. Voltage components and current components is used of double insulation structure, has good electrical characteristics.

4. Standard configuration bottom bearing is used of double gem bearing, oriented bearing is made of high wear resistance copper alloy bush and stainless steel needle. It has following features: long life and minimal friction, etc. May select magnetic thrust bearing (Product Configuration code is UE).

5. All kinds of adjustment mechanism adopt no step shifting mechanism. The meter starting and creeping needn’t to be adjusted which is finished by anti-creeping hole of disc and convenient for adjusting by users.

6. Standard configuration 6 digits display by drum wheel mechanical register, may select 5 digits display by drum wheel mechanical register (Product Configuration code is UH).

7. Standard configuration without the device which can prevent retrograde, may select add the function of prevent retrograde. (Please specified when ordering).

8. Single component measure single phase two wire active energy consumption. Complying with standard IEC 62053-11.

9. Direct connect operation, there are two types wiring you may select. Standard configuration type 1A wiring, may select type 1B wiring (Product Configuration code is UJ).

10. Standard configuration extension terminals cover, in order to protect to use safety, may select short terminals cover. (Product Configuration code is TK).

Technical parameters

Dimension and wiring
