1kw 96v wind turbine 10kw wind generators fan 2kw 3kw 5kw wind generator
Hits: 5498
Price: 559.00Dollar/sets
Min quantity: 20 sets
Quantity: 3000 sets
Deliver: In days
Expiry: Long-term
Update date 2022-10-13 10:24

Detail

1.low start up speed; high wind energy utilization; beautiful appearance; low vibration
2.Human friendly design, easy installation, maintenance and repair.
3.precise injection molding blades together with the optimized design of aerodynamic contour and structure, the blades have such
advantages: high utilization of wind energy which contributes to the annual energy output.
4.the generators, adopting patented permanent magnet rotor alternator,with a special kind of stator design, efficiently decrease
resistance torque.Meanwhile, it makes the wind turbines match the generators quite well and increase its reliability

Package list:

1. one set wind turbine .
2.one set bolts and nuts.
3.one piece flange.
4. one piece charge controller.

Des/Model

FK-1000

Rated Power

1000W

maximum power

2000W

Rated voltage

48/100V

Start up wind speed

2.5m/s

Rated wind speed

10m/s

Security wind speed

40m/s

Net weight

40kg

wheel Diameter

2.8m

Package weight

50kg

Packing size

1600*500*450mm

Blade number

3pcs

Blade material

nylon fiber

body material

A3

Generator

Three-phase permanent magnet ac synchronousGenerator

Control System

Electromagnet

Yaw mode

3,5KW Folding tail /10-20 Electronic yaw

Insulation

Insulation

Tower

Cable / Independent tower

Working Temperature

-40ºC-80ºC

1. A3 steel housing, makes small size, light weight, beautiful appearance and low working vibration.
2. flange connection ensures good strength, easy installation and maintenance.
3. enhanced fiberglass turbine blades with optimized aerodynamic shape design and structural design could lead low wind speed
start, high wind energy utilization. The blade surface is coated by gel coat resin and painted to resist corrosion by air and
water.
4. the automatic-yaw tail rudder empowers this horizontal swing-tail wind turbine (the tail automatically swings in high wind and
automatically return in safe wind)a higher anti-typhoon capacity.
5. the generator adopts permanent magnet external rotor design, which has a much better heat dissipation performance than inner
rotor design. Coupled with a special-designed stator, the resistance torque has been effectively reduced.
6. 42NSH magnetic steel piece has stronger magnetism and higher temperature resistance.
7. F-class enameled wire could stand 150 degrees temperature, coil operation safety is ensured.
8. the body shell is dacromet coated and twice anti-corrosion painted, to ensure rust free after a long time operation.

Residential Hybrid System Use 1000w wind generator alternative energy generators turbine generator

1000w wind generator turbine generator alternative energy generators

The shipping method and costs are not the best for all countries, please contact us to check the best shipping way to your address and we will try to give you the biggest discount.

Engineering projects and customer feedback from around the world

1,Competitive Price

--We are the factory/manufacturer so we can control production costs and then sell at the lowest price.


2,Controllable quality

--All products will be produced in our factory so we can show you every detail of the production and let you check the quality of the order.


3. Multiple payment methods

-- We accept online Alipay, bank transfer,Paypal ,LC, Western union etc.


4,Various forms of cooperation

--We are not only offer you our products, if it is needed, we could be your partner and design product according to your requirement. Our factory is your factory!


5.perfect after-sales service

--As a manufacturer of wind turbine and generator products for over 4 years,we are very experiences to dealing all kinds of problems. So whatever happens,we will solve it at the first time.
