Specifications | |
Model | SC230BR |
Engine type | Single cylinder, 4 Stroke, Forced Coolling OHV |
Bore x Stroke (mm) | 70x58 |
Displacement | 223cc |
Compression | 8.5 : 1 |
Starting method | Recoil/E-start |
Ignition method | Transistorized ignition |
Lubrication method | Splash |
Rated output(Kw-r/mim) | 5.5-4500 |
Max torque(N.m-r/min) | 12.5-2500 |
Min.fuel consumption(g/Kw.h) | ≤374 |
Dimensions L*W*H (mm) | 380*360*270 |
Net weight (kgs) | 16.3 |
Loading Qty (20GP/40HQ) | 768/1782 |
